Master bag  550 TL

In-line twisted handle for twisted paper bag

varying greatly sizes at a high speed, thus is especially suitable for being applied in food and Shopping industrie

 Paper bag cutting length (C) 380-650mm
(380-770mm)
Paper bag width (W) 220-540mm
Paper bag bottom width (H) 80-250 mm
Paper thickness 90-170g/m2
Max. Paper bag speed 120pcs/min
Paper roll width 630-1510mm
Paper roll diameter Dia 1200mm
The inner diameter of the paper roll Dia is 76mm
Handle rope height 110-120mm
Handle rope diameter Dia4-6mm
Handle sheet length 190.5mm
Handle sheet width 80-100mm
Machine supply 380V, 50Hz, three-phase, four wires
Power 39KW
Weight 20000 KGS
Dimension L14000*W6000*H3100mm
PLC Yaskawa Japan
Servo Motor Yaskawa Japan
Servo Driver Yaskawa Japan
Cylinder AirTac Taiwan
Low Voltage Electrical Apparatus Schneider Germany
Normal Button Schneider Germany
Emergency Button Schneider Germany
Bearing NSK Japan
Solenoid valve AirTac Taiwan
Photoelectric Eye Color Code Tracking SICK Germany
