BOTTOMER W&H AD 2360-16
yEAR OF PRODUCTION 1975
Tube Lengths - w/ min bottom width - 480mm - 1280mm
- w/ max bottom width - 650mm - 1400mm
Centre to centre distance of bottoms - 300mm - 1100mm
Bottom width (flush cut) - 75mm - 160mm
Bottom width (stepped end sacks) - 75mm - 150mm
Dimensions of opened up bottom - 18mm - 360mm
Sack length (flush cut) - 370mm - 1220mm
Sack length (stepped end) - 370mm - 1200mm
Tube width - 300mm - 650mm
Valve length - 90mm - 250mm
Length of valve fold - 10mm - 60mm
Roll width - 110mm - 350mm
Prefabricated tubular valve - 90mm - 160mm
cut-off length selectable in steps of… - 33mm
