- ROTOPAC 2000 –
- Serial No. 73061 ( made 1988 ), Rotomec
- rotogravure 8 colour printing machine
- left to right handled
- web width 480 mm - 1020 mm
- Print width max, 1000 mm
- printing cylinder circumference range 350-820 mm
- max. reel diameter unwinder 800 mm
- max. reel diameter rewinder 800 mm
- inner core diameter unwinder 70,76
- inner core diameter rewinder 70,76 mm
- adaptors for inner core diameter 150 mm on unwinder
- Automatic splicing unwinder and rewinder
- max. mechanical speed 250 m/min
- min. operating speed 12,5 m/min
- Possibilites for reversing printing 7+1 colour
- Compressed air 7 bar
- Preconditioning group
- 16 trolleys ( 8 in machine + 8 out of machine)
- Heating by gas burners ( heating source by gas )
- Electric main power 380 V/50 Hz
- 16 antistatic rubber rollers
- Installed power 250 KW
- Temperature of cool water 12 C-15 C
- Diameter of pipes for cool water is 2"
- Supply pressure of gas 100 mbar
- Diameter of supply pipes for gas 1"
- 4 burner station Maxon
Materials could be handled :
- Al-foil 8-60μ
- PE 30-100μ
- Poliester 12-36μ
- OPP 13-40μ
- Papir max. 100 g/m²
- Different substrates up to 150 gr/m²
